GPM RACING,TRAXXAS CORVETTE STINGARY 4WD FORD GT 4-TEC 2.0 GPM RACING ALUMINUM 7075 MOTOR MOUNT PLATE WITH HEAT SINK FINS GT018N

Packaging Includes:
Motor Mount-1pcs
Grade 12.9 black Cap Head Screws 3x10-2pcs

Original Name / Part No:
8390

Part location:
Motor area

Does this product replace a specific part or function:
Yes

Product major functions & usage ¡G
Stabilize the motor, fast cooling with fins.

Is this part adjustable? If yes ¡K how and why/purpose?
How and why --- There are 11 positioning holes (A, B, C, D, E, F, G, H, I, J, K) for different mounting position.
Purpose --- Adjust the motor gear and spur gear distance (PITCH) to keep the car's stability.
Major advantages of upgrading to this part/product¡G
Made with a quality light weight high tensile strength aluminum 7075 for great durability and better stability of the motor. Better heat displacement for the motor to cool down during an intense drive,On top of the original design, this part has added some fins on the design for better heat displacement.
Intallation:
According to original spur gear 70T, 4 holes from A to D are confirmed
From A to A, please use 20T pinion
From B to B, please use 21T pinion
From C to C, please use 22T pinion
From D to D, please use 23T pinion

Suitable Model:
TRAXXAS 1/10 4WD FORD GT 4-TEC 2.0 83056-4
TRAXXAS 1/10 4-TEC 3.0 CORVETTE STINGARY-93054-4
TRAXXAS 1/10 4-Tec 2.0 AWD Chassis with brushed power system-83024-4
TRAXXAS 1/10 4-Tec 2.0 Brushless AWD Chassis with BL-2S power system-83124-4
TRAXXAS 1/10 4-Tec 2.0 VXL AWD Chassis with velineon brushless system-83076-4
TRAXXAS 1/10 Factory Five 1933 Hot Rod Coupe-93044-4
TRAXXAS 1/10 Factory Five 1935 Hot Rod Truck-93034-4
TRAXXAS 1/10 Ford Mustang GT-83044-4
TRAXXAS 1/10 Toyota GR Supra GT4-93064-4
