GPM RACING TRAXXAS SLEDGE ALUMINUM 7075-T6 CHASSIS PLATE WITH SERVO MOUNT+BATTERY COMPARTMENT+MOTOR BASE SLE1612638B

Packaging Includes:
SLE016
Chassis Plate-1pc
GSLE0126A
Aluminum 7075-T6 fixing strip-1pc
Carbon Fibre battery panel-1pc
Square buckle Velcro-2pcs
Velcro-1pc
Servo mount-1pc
Flat Head Screw 4*10-5pcs
Flat Head Screw 3*10-6pcs
Flat Head Screw 3*6-1pc
Round Head Screw 3x12-4pcs
SLE038AN
Differential & motor mount-6pcs
Stainless steel flat head screw 4x12-5pcs
Stainless steel flat head screw 3x14-2pcs
Stainless steel flat head screw 3x8-4pcs
Stainless steel round head screw 4x12-2pcs
Stainless steel round head screw 4x10-4pcs
Stainless steel round head screw 3x8-2pcs
Stainless steel cap head screws 4*16-2pcs
Stainless steel cap head screws 3*12-1pc
Stainless steel washer 1*4*8-2pcs
Stainless steel washer 1*3*6-1pc
(Some screws are installed on the goods)

Original Name / Part No:
9522+9626+9584

Part Location:
Below front, center, rear chassis+battery+Back of center differential

Does this product replace a specific part or function?
No

Product major function & usage:
Increase the firmness of the chassis, impact-resistant and wear-resistant, and strengthen the body structure
Fixed battery
Stabilize center differential and motor

Major advantages of upgrading to this product:
(1) The material is upgraded to aluminum 7075-T6, the chassis is thickened from 3.2mm to 4.0mm, making it more sturdy.
(2) Upgrade the reinforced edges to 5mm thickness and adding the groove in between to help reduce bending.
(3) There is a reserved position for the extended motor on the electric seat. It means that GPM will also produce a motor mount for this extended motor later.
(4) GPM aluminum 7075-T6 servo mount and battery compartment integrated, the battery compartment retains the original quick-release voltage plate, which is convenient for disassembly and installation of the servo mount.

(5) The fixing strip of the carbon fibre battery panel at the bottom is made of aluminum 7075-T6, which enhances the firmness of the servo mount and the battery compartment.
(6) The open design with Velcro is compatible with different sizes of batteries, and the adjustment is more flexible, so the battery is not easy to fall off during use.
(7) The reverse quick release version is compatible with the installation of 4985. 1717 and other motors, can be easily powered by 8S.
(8) The convenient quick release motor base is redeveloped by GPM to effectively prevent the displacement of the motor.
(9) The motor hole is reserved for 3mm/4mm, which can be compatible with the installation of multiple types of motors.
Note: This product requires to use with ARRMA AR320422 receiver box.

Suitable Model:
TRAXXAS-1/8 4WD SLEDGE MONSTER TRUCK-95076-4
