TP 4070-CM 2810kv Brushless Motor ( up to 6s )

$194.95
Shipping calculated at checkout.

ROTOR SHAFT SIZE


Description

TP 4070-CM 2810KV (6S) BRUSHLESS MOTOR DRAG/SPEEDRUN This model is specially winded for 6S application.TP Power motors are made of the best materials that are available, and have high efficiencies (>90%) required for the most demanding applications.The TP 4070-CM Series is our most powerful 40 series up to date, with 75K max burst RPM. Parameters:Can: SmoothT: 5DKV: 2810Max Amps (A): 321Max Volt (V): 28Continuous Power (W): 5000Max Power (W): 9000 for 10 secondsMax RPM: 75 K for 10 secondsInternal Resistance (Ohm): 0.021No-load Current (A): 10.9 at 7.5VShaft Diameter (mm): 5 or 8Diameter X Length (mm): 40 X 107Output Shaft Length (mm): 18Bolt Pattern: 4 - M4 - 25mmWeight: 640 gPole: 4-pole THIS ITEM SHIPS WORLDWIDE. THANK YOU
vendor-unknown

TP 4070-CM 2810kv Brushless Motor ( up to 6s )

$194.95
TP 4070-CM 2810KV (6S) BRUSHLESS MOTOR DRAG/SPEEDRUN This model is specially winded for 6S application.TP Power motors are made of the best materials that are available, and have high efficiencies (>90%) required for the most demanding applications.The TP 4070-CM Series is our most powerful 40 series up to date, with 75K max burst RPM. Parameters:Can: SmoothT: 5DKV: 2810Max Amps (A): 321Max Volt (V): 28Continuous Power (W): 5000Max Power (W): 9000 for 10 secondsMax RPM: 75 K for 10 secondsInternal Resistance (Ohm): 0.021No-load Current (A): 10.9 at 7.5VShaft Diameter (mm): 5 or 8Diameter X Length (mm): 40 X 107Output Shaft Length (mm): 18Bolt Pattern: 4 - M4 - 25mmWeight: 640 gPole: 4-pole THIS ITEM SHIPS WORLDWIDE. THANK YOU

ROTOR SHAFT SIZE

  • 5mm
  • 8mm
